This module contains subroutines related to the equations of state and other properties such as relative permeabilities, capillary, flash, etc. More...

Functions/Subroutines
subroutine	calculate_all_rhos (state, packed_state, Mdims, get_RhoCp)
	: Computes the density for the phases and the derivatives of the density More...

subroutine	cap_bulk_rho (state, ncomp, nphase, cv_nonods, Density_Component, Density, Density_Cp, compute_rhoCP)
	: Computes the bulk density for components and the derivatives of the density More...

subroutine	calculate_component_rho (state, packed_state, Mdims)
	: Computes the density for the components and the derivatives of the density This is were the action is actually done, the other calculate rhos are wrappers More...

subroutine	calculate_rho_drhodp (state, packed_state, iphase, icomp, nphase, ncomp, eos_option_path, rho, drhodp)
	: Computes the density and the derivative of the density More...

subroutine	calculate_porous_rho_drhop (state, packed_state, Mdims, cv_ndgln, drhodp_porous)
	In this subroutine we calculate and update the density of the porous media based on the compressibility given in Diamond (ele-wise). We also calculate the drho/dp term for the porous media which then goes into the DERIV term in the continuity equation (cv-wise). More...

subroutine	density_polynomial (eos_coefs, pressure, temperature, Density_Field)
	: Define de density as a polynomial More...

subroutine	assign_equation_of_state (eos_option_path_out)
	: Read from diamond and decide which sort of density representation do we have More...

subroutine	calculate_porousmedia_absorptionterms (nphase, state, packed_state, PorousMedia_absorp, Mdims, CV_funs, CV_GIdims, Mspars, ndgln, upwnd, suf_sig_diagten_bc)
	: Here we compute the absorption for porous media This is the sigma term defined in the papers and contains The permeability, the relative permeability, the viscosity and the saturation More...

subroutine	calculate_absorption2 (nphase, packed_state, PorousMedia_absorp, Mdims, ndgln, SATURA, viscosities, inv_PorousMedia_absorp)
	: Subroutine where the absorption for the porous media is actually computed More...

subroutine	get_material_absorption (nphase, iphase, material_absorption, sat, visc, CV_Immobile_fract, Corey_exponent, Endpoint_relperm)
	:Calculates the relative permeability for 1, 2 (Brooks-corey) or 3 (stone's model) phases More...

subroutine	get_relperm (nphase, iphase, sat, CV_Immobile_fract, Corey_exponent, Endpoint_relperm, Kr)
	:Calculates the relative permeability for 1, 2 (Brooks-corey) or 3 (stone's model) phases More...

subroutine	calculate_capillary_pressure (packed_state, NDGLN, totele, cv_nloc, CV_funs)
	: In this subroutine the capilalry pressure is computed based on the saturation and the formula used More...

real function	get_devcappressure (sat, Pe, a, CV_Immobile_Fraction, iphase, nphase)
	:This functions returns the derivative of the capillary pressure with respect to the saturation More...

subroutine	calculate_u_source_cv (Mdims, state, packed_state, den, u_source_cv)
	: This subroutine computed the gravity effect, i.e. rho * g More...

subroutine	calculate_diffusivity (state, packed_state, Mdims, ndgln, ScalarAdvectionField_Diffusion, TracerName, divide_by_rho_CP)
	: Here we compute component/solute/thermal diffusion coefficient More...

subroutine	calculate_solute_dispersity (state, packed_state, Mdims, ndgln, density, SoluteDispersion)
	: Dispersion for porous media For thermal, the field density needs to be passed down, which ensures that even for boussinesq a reference density is still used More...

subroutine	calculate_viscosity (state, Mdims, ndgln, Momentum_Diffusion, Momentum_Diffusion2)
	: Computes the viscosity effect as a momemtum diffusion, this is zero for porous media More...

subroutine	update_velocity_absorption (states, ndim, nphase, velocity_absorption)
	:<INERTIA ONLY>Computes velocity absorption from diamond information More...

subroutine	update_velocity_absorption_coriolis (states, ndim, nphase, velocity_absorption)
	:Computes velocity absorption associated to coriolis forces from diamond information More...

subroutine	update_velocity_source (states, Mdims, u_source)
	:Computes velocity source from diamond information More...

real function	saturation_temperature (pressure)
	: ???? More...

subroutine	get_rockfluidprop (state, packed_state, Mdims, ndgln, current_time, update_only)
	:Gets the relperm max, the relperm exponent and the immobile fractions and stores them into packed state By index this is: 1) immobile fraction, 2) relperm max, 3)relperm exponent 4)Capillary entry pressure 5) Capillary exponent 6) Capillary imbition term The effective inmobile fraction is the min(inmobile,saturation_flipping formula), being the saturation the value after a succesful non-linear solver convergence! This NEEDS to be called after a succesful non-linear solver (with update_only) More...

real function	jwl (A, B, w, R1, R2, E0, p, roe, ro)
	JWL equation functions. More...

real function	diffjwl (A, B, w, R1, R2, E0, roe, ro)
	Diff of JWL equation functions. More...

real function, dimension(jwln)	jwldensity (eos_coefs, pressure, ro0, JWLn)
	Density of JWL equation functions. More...

subroutine	initialise_porous_media (Mdims, ndgln, packed_state, state, exit_initialise_porous_media)
	: Initialising porous media models Given a free water level (FWL) we simulate capillary gravity equilibration, control volumes below FWL is kept at residual lighter phase saturation This subroutine is called after each timestep and saturations overidden below FWL with the heavier phase More...

real function	retrieve_reference_density (state, packed_state, iphase, icomp, nphase)
	: For boussinesq porous media we need the reference density to ensure consistency when mixing with the porous density/Cp etc. In this subroutine we retrieve the value given a phase, component. More...

subroutine	flash_gas_dissolution (state, packed_state, Mdims, ndgln)
	: subroutine to dissolv phase2 into phase1. Currently only for system for phase 1 = water, phase 2 = gas Dissolve instantaneously the amount introduced in diamond in mol/m3 for CO2 a reference number is 38 mol/m3. Requires the first phase to have a concentration field More...

Variables
real, parameter	flooding_hmin = 1e-5

Detailed Description

This module contains subroutines related to the equations of state and other properties such as relative permeabilities, capillary, flash, etc.

Function/Subroutine Documentation

◆ assign_equation_of_state()

subroutine multiphase_eos::assign_equation_of_state ( character( len = option_path_len ), intent(inout) eos_option_path_out )

: Read from diamond and decide which sort of density representation do we have

Parameters

eos_option_path_out Diamond path of the EOS to be used

Here is the caller graph for this function:

◆ calculate_absorption2()

subroutine multiphase_eos::calculate_absorption2	(	integer, intent(in)	nphase,
		type( state_type ), intent(inout)	packed_state,
		type (multi_field)	PorousMedia_absorp,
		type(multi_dimensions), intent(in)	Mdims,
		type(multi_ndgln), intent(in)	ndgln,
		real, dimension( :, : ), intent(in)	SATURA,
		real, dimension(:,:), intent(in)	viscosities,
		real, dimension(:,:,:), intent(inout), optional	inv_PorousMedia_absorp
	)

: Subroutine where the absorption for the porous media is actually computed

Parameters

nphase	Number of phases
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
PorousMedia_absorp	INOUT Absorption associated to the porous media
Mdims	Number of dimensions
ndgln	Global to local variables
SATURA	PhasevolumeFraction field
viscosities	viscosity field
inv_PorousMedia_absorp	(optional) INOUT inverse of the absorption term

Here is the call graph for this function:

Here is the caller graph for this function:

◆ calculate_all_rhos()

subroutine multiphase_eos::calculate_all_rhos	(	type( state_type ), dimension( : ), intent(inout)	state,
		type( state_type ), intent(inout)	packed_state,
		type(multi_dimensions), intent(in)	Mdims,
		logical, intent(in), optional	get_RhoCp
	)

: Computes the density for the phases and the derivatives of the density

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
Mdims	Data type storing all the dimensions describing the mesh, fields, nodes, etc
get_RhoCp	This flags computes rhoCp instead of rho

Here is the call graph for this function:

Here is the caller graph for this function:

◆ calculate_capillary_pressure()

subroutine multiphase_eos::calculate_capillary_pressure	(	type(state_type), intent(inout)	packed_state,
		type(multi_ndgln), intent(in)	NDGLN,
		integer, intent(in)	totele,
		integer, intent(in)	cv_nloc,
		type(multi_shape_funs)	CV_funs
	)

: In this subroutine the capilalry pressure is computed based on the saturation and the formula used

Parameters

packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
ndgln	Global to local variables
Totele	Total number of elements
cv_nloc	Total number of CVs per element
CV_funs	Shape functions for the CV mesh

Here is the call graph for this function:

Here is the caller graph for this function:

◆ calculate_component_rho()

subroutine multiphase_eos::calculate_component_rho	(	type( state_type ), dimension( : ), intent(inout)	state,
		type( state_type ), intent(inout)	packed_state,
		type( multi_dimensions ), intent(in)	Mdims
	)

: Computes the density for the components and the derivatives of the density This is were the action is actually done, the other calculate rhos are wrappers

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
Mdims	Data type storing all the dimensions describing the mesh, fields, nodes, etc

Here is the call graph for this function:

Here is the caller graph for this function:

◆ calculate_diffusivity()

subroutine multiphase_eos::calculate_diffusivity	(	type(state_type), dimension(:), intent(in)	state,
		type( state_type ), intent(inout)	packed_state,
		type(multi_dimensions), intent(in)	Mdims,
		type(multi_ndgln), intent(in)	ndgln,
		real, dimension(:, :, :, :), intent(inout)	ScalarAdvectionField_Diffusion,
		character(len=*), intent(in), optional	TracerName,
		logical, intent(in), optional	divide_by_rho_CP
	)

: Here we compute component/solute/thermal diffusion coefficient

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
Mdims	Number of dimensions
ndgln	Global to local variables
ScalarAdvectionField_Diffusion	INOUT Field containing the diffusion
divide_by_rho_CP	! If we want to normlise the equation by rho CP we can return the diffusion coefficient divided by rho Cp
TracerName	! For PassiveTracer with diffusion we pass down the name of the tracer

Here is the caller graph for this function:

◆ calculate_porous_rho_drhop()

subroutine multiphase_eos::calculate_porous_rho_drhop	(	type( state_type ), dimension( : ), intent(inout)	state,
		type( state_type ), intent(inout)	packed_state,
		type(multi_dimensions), intent(in)	Mdims,
		integer, dimension( : ), intent(in)	cv_ndgln,
		real, dimension( : ), intent(inout)	drhodp_porous
	)

In this subroutine we calculate and update the density of the porous media based on the compressibility given in Diamond (ele-wise). We also calculate the drho/dp term for the porous media which then goes into the DERIV term in the continuity equation (cv-wise).

Author: Geraldine Regnier

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
Mdims	Number of dimensions
cv_ndgln	Global to local variables for the CV mesh
drhodp.	Derivative of the porous density

Here is the caller graph for this function:

◆ calculate_porousmedia_absorptionterms()

subroutine multiphase_eos::calculate_porousmedia_absorptionterms	(	integer, intent(in)	nphase,
		type( state_type ), dimension( : ), intent(inout)	state,
		type( state_type ), intent(inout)	packed_state,
		type (multi_field)	PorousMedia_absorp,
		type( multi_dimensions ), intent(in)	Mdims,
		type(multi_shape_funs), intent(inout)	CV_funs,
		type( multi_gi_dimensions ), intent(in)	CV_GIdims,
		type (multi_sparsities), intent(in)	Mspars,
		type(multi_ndgln), intent(in)	ndgln,
		type (porous_adv_coefs), intent(inout)	upwnd,
		real, dimension( :, : ), intent(inout)	suf_sig_diagten_bc
	)

: Here we compute the absorption for porous media This is the sigma term defined in the papers and contains The permeability, the relative permeability, the viscosity and the saturation

Parameters

nphase	Number of phases
state	Linked list containing all the fields defined in diamond and considered by Fluidity
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
PorousMedia_absorp	INOUT Absorption associated to the porous media
Mdims	Number of dimensions
CV_funs	Shape functions for the CV mesh
CV_GIdims	Gauss integration numbers for CV fields
Mspars	Sparsity of the matrices
ndgln	Global to local variables
upwnd	Sigmas to compute the fluxes at the interphase for porous media
SUF_SIG_DIAGTEN_BC	Like upwnd but for the boundary

Here is the call graph for this function:

Here is the caller graph for this function:

◆ calculate_rho_drhodp()

subroutine multiphase_eos::calculate_rho_drhodp	(	type( state_type ), dimension( : ), intent(inout)	state,
		type( state_type ), intent(inout)	packed_state,
		integer, intent(in)	iphase,
		integer, intent(in)	icomp,
		integer, intent(in)	nphase,
		integer, intent(in)	ncomp,
		character( len = option_path_len ), intent(in)	eos_option_path,
		real, dimension( : ), intent(inout)	rho,
		real, dimension( : ), intent(inout)	drhodp
	)

: Computes the density and the derivative of the density

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
iphase	current phase
icomp	current component
nphase	number of phases
ncomp	number of components
eos_option_path	Path in diamond of the EOS to be used
rho	density
drhodp.	Dderivative of density

Here is the call graph for this function:

Here is the caller graph for this function:

◆ calculate_solute_dispersity()

subroutine multiphase_eos::calculate_solute_dispersity	(	type(state_type), dimension(:), intent(in)	state,
		type( state_type ), intent(inout)	packed_state,
		type(multi_dimensions), intent(in)	Mdims,
		type(multi_ndgln), intent(in)	ndgln,
		real, dimension(:,:), intent(in), target	density,
		real, dimension(:, :, :, :), intent(inout)	SoluteDispersion
	)

: Dispersion for porous media For thermal, the field density needs to be passed down, which ensures that even for boussinesq a reference density is still used

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
Mdims	Number of dimensions
ndgln	Global to local variables
density	Density of the field (If present density means that we need to use a reference density to ensure consistency with the rest of the equation)
SoluteDispersion	INOUT The field containing the dispersivity controbution for the given field

Here is the caller graph for this function:

◆ calculate_u_source_cv()

subroutine multiphase_eos::calculate_u_source_cv	(	type(multi_dimensions), intent(in)	Mdims,
		type(state_type), dimension(:), intent(in)	state,
		type( state_type ), intent(inout)	packed_state,
		real, dimension(:,:), intent(in)	den,
		real, dimension(:,:,:), intent(inout)	u_source_cv
	)

: This subroutine computed the gravity effect, i.e. rho * g

Parameters

Mdims	Number of dimensions
state	Linked list containing all the fields defined in diamond and considered by Fluidity
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
den	Density field
u_source_cv	INOUT Source term having now the gravity term

Here is the call graph for this function:

Here is the caller graph for this function:

◆ calculate_viscosity()

subroutine multiphase_eos::calculate_viscosity	(	type( state_type ), dimension( : ), intent(in)	state,
		type( multi_dimensions ), intent(in)	Mdims,
		type( multi_ndgln ), intent(in)	ndgln,
		real, dimension( :, :, :, : ), intent(inout)	Momentum_Diffusion,
		type( multi_field ), intent(inout)	Momentum_Diffusion2
	)

: Computes the viscosity effect as a momemtum diffusion, this is zero for porous media

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
Mdims	Number of dimensions
ndgln	Global to local variables
Momentum_Diffusion	Viscosity term for Stokes/Navier-Stokes
Momentum_Diffusion2	Shear viscosity?

Here is the caller graph for this function:

◆ cap_bulk_rho()

subroutine multiphase_eos::cap_bulk_rho	(	type(state_type), dimension( : )	state,
		integer, intent(in)	ncomp,
		integer, intent(in)	nphase,
		integer, intent(in)	cv_nonods,
		real, dimension( cv_nonods * nphase * ncomp ), intent(in)	Density_Component,
		real, dimension( cv_nonods * nphase ), intent(inout)	Density,
		real, dimension( cv_nonods * nphase ), intent(inout)	Density_Cp,
		logical, intent(in)	compute_rhoCP
	)

: Computes the bulk density for components and the derivatives of the density

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
ncomp	number of components
nphase	number of phases
cv_nonods	number of CV nodes
Density_Component	density of a component for compositional modelling
Density	(self descriptive)
Density_Cp.	Density times Cp
compute_rhoCP	This flags computes rhoCp instead of rho

Here is the caller graph for this function:

◆ density_polynomial()

subroutine multiphase_eos::density_polynomial	(	real, dimension( : ), intent(in)	eos_coefs,
		real, dimension( : ), intent(in)	pressure,
		real, dimension( : ), intent(in)	temperature,
		real, dimension( : ), intent(inout)	Density_Field
	)

: Define de density as a polynomial

Here is the caller graph for this function:

◆ diffjwl()

real function multiphase_eos::diffjwl	(	real, intent(in)	A,
		real, intent(in)	B,
		real, intent(in)	w,
		real, intent(in)	R1,
		real, intent(in)	R2,
		real, intent(in)	E0,
		real, intent(in)	roe,
		real, intent(in)	ro
	)

Diff of JWL equation functions.

Here is the caller graph for this function:

◆ flash_gas_dissolution()

subroutine multiphase_eos::flash_gas_dissolution	(	type(state_type), dimension(:), intent(inout)	state,
		type(state_type), intent(inout)	packed_state,
		type(multi_dimensions), intent(in)	Mdims,
		type(multi_ndgln), intent(in)	ndgln
	)

: subroutine to dissolv phase2 into phase1. Currently only for system for phase 1 = water, phase 2 = gas Dissolve instantaneously the amount introduced in diamond in mol/m3 for CO2 a reference number is 38 mol/m3. Requires the first phase to have a concentration field

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
Mdims	Data type storing all the dimensions describing the mesh, fields, nodes, etc
ndgln	Global to local variables

Here is the caller graph for this function:

◆ get_devcappressure()

real function multiphase_eos::get_devcappressure	(	real, intent(in)	sat,
		real, intent(in)	Pe,
		real, intent(in)	a,
		real, dimension(:), intent(in)	CV_Immobile_Fraction,
		integer, intent(in)	iphase,
		integer, intent(in)	nphase
	)

:This functions returns the derivative of the capillary pressure with respect to the saturation

Parameters

Sat	Phase Volume fraction at current CV
Pe	Entry pressure at current ELE
a	Exponent at current ELE
CV_Immobile_Fraction	Immobile fraction at current CV
iphase	current phase
nphase	Number of phases

Here is the caller graph for this function:

◆ get_material_absorption()

subroutine multiphase_eos::get_material_absorption	(	integer, intent(in)	nphase,
		integer, intent(in)	iphase,
		real, intent(inout)	material_absorption,
		real, dimension(:), intent(in)	sat,
		real, dimension(:), intent(in)	visc,
		real, dimension(:), intent(in)	CV_Immobile_fract,
		real, dimension(:), intent(in)	Corey_exponent,
		real, dimension(:), intent(in)	Endpoint_relperm
	)

:Calculates the relative permeability for 1, 2 (Brooks-corey) or 3 (stone's model) phases

Parameters

nphase	Number of phases
iphase	current phase
material_absorption	INOUT Absorption associated to the porous media
sat	saturation at current CV
visco	viscosity at current CV
CV_Immobile_fract	Immobile fraction at current CV
Corey_exponent	Exponent of the relperm curve at current ELE
Endpoint_relperm	End point of the relperm curve at current ELE

Here is the call graph for this function:

Here is the caller graph for this function:

◆ get_relperm()

subroutine multiphase_eos::get_relperm	(	integer, intent(in)	nphase,
		integer, intent(in)	iphase,
		real, dimension(:), intent(in)	sat,
		real, dimension(:), intent(in)	CV_Immobile_fract,
		real, dimension(:), intent(in)	Corey_exponent,
		real, dimension(:), intent(in)	Endpoint_relperm,
		real, intent(inout)	Kr
	)

:Calculates the relative permeability for 1, 2 (Brooks-corey) or 3 (stone's model) phases

Parameters

nphase	Number of phases
iphase	current phase
sat	saturation at current CV
CV_Immobile_fract	Immobile fraction at current CV
Corey_exponent	Exponent of the relperm curve at current ELE
Endpoint_relperm	End point of the relperm curve at current ELE
Kr	INOUT Relative permeability at current CV

Here is the call graph for this function:

Here is the caller graph for this function:

◆ get_rockfluidprop()

subroutine multiphase_eos::get_rockfluidprop	(	type(state_type), dimension(:), intent(inout)	state,
		type( state_type ), intent(inout)	packed_state,
		type( multi_dimensions ), intent(in)	Mdims,
		type( multi_ndgln ), intent(in)	ndgln,
		real, intent(in), optional	current_time,
		logical, intent(in), optional	update_only
	)

:Gets the relperm max, the relperm exponent and the immobile fractions and stores them into packed state By index this is: 1) immobile fraction, 2) relperm max, 3)relperm exponent 4)Capillary entry pressure 5) Capillary exponent 6) Capillary imbition term The effective inmobile fraction is the min(inmobile,saturation_flipping formula), being the saturation the value after a succesful non-linear solver convergence! This NEEDS to be called after a succesful non-linear solver (with update_only)

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
Mdims	Data type storing all the dimensions describing the mesh, fields, nodes, etc
ndgln	Global to local variables
current_time	current time in type(real). Only for the first time ever, not for checkpointing, overwrite the saturation flipping value with the initial one
update_only	If true then only the Immobile fraction is updated (for Land trapping modelling only)

Here is the call graph for this function:

Here is the caller graph for this function:

◆ initialise_porous_media()

subroutine multiphase_eos::initialise_porous_media	(	type(multi_dimensions), optional	Mdims,
		type(multi_ndgln), optional	ndgln,
		type(state_type), optional	packed_state,
		type(state_type), dimension(:), optional	state,
		logical, intent(inout)	exit_initialise_porous_media
	)

: Initialising porous media models Given a free water level (FWL) we simulate capillary gravity equilibration, control volumes below FWL is kept at residual lighter phase saturation This subroutine is called after each timestep and saturations overidden below FWL with the heavier phase

Parameters

Mdims	Data type storing all the dimensions describing the mesh, fields, nodes, etc
ndgln	Global to local variables
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
state	Linked list containing all the fields defined in diamond and considered by Fluidity
exit_initialise_porous_media	Activates the option to after initialising stop the simulation

Here is the caller graph for this function:

◆ jwl()

real function multiphase_eos::jwl	(	real, intent(in)	A,
		real, intent(in)	B,
		real, intent(in)	w,
		real, intent(in)	R1,
		real, intent(in)	R2,
		real, intent(in)	E0,
		real, intent(in)	p,
		real, intent(in)	roe,
		real, intent(in)	ro
	)

JWL equation functions.

Here is the caller graph for this function:

◆ jwldensity()

real function, dimension( jwln ) multiphase_eos::jwldensity	(	real, dimension( : ), intent(in)	eos_coefs,
		real, dimension( : ), intent(in)	pressure,
		real, dimension( : ), intent(in)	ro0,
		integer, intent(in)	JWLn
	)

Density of JWL equation functions.

Here is the call graph for this function:

◆ retrieve_reference_density()

real function multiphase_eos::retrieve_reference_density	(	type( state_type ), dimension( : ), intent(in)	state,
		type( state_type ), intent(inout)	packed_state,
		integer, intent(in)	iphase,
		integer, intent(in)	icomp,
		integer, intent(in)	nphase
	)

: For boussinesq porous media we need the reference density to ensure consistency when mixing with the porous density/Cp etc. In this subroutine we retrieve the value given a phase, component.

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
packed_state	Linked list containing all the fields used by IC-FERST, memory partially shared with state
iphase	Current phase
icomp	current component
nphase	Number of phases

Here is the call graph for this function:

Here is the caller graph for this function:

◆ saturation_temperature()

real function multiphase_eos::saturation_temperature ( real pressure )

: ????

◆ update_velocity_absorption()

subroutine multiphase_eos::update_velocity_absorption	(	type( state_type ), dimension( : ), intent(in)	states,
		integer, intent(in)	ndim,
		integer, intent(in)	nphase,
		real, dimension( :, :, : ), intent(inout)	velocity_absorption
	)

:<INERTIA ONLY>Computes velocity absorption from diamond information

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
ndim	Number of dimensions
nphase	Number of phases
velocity_absorption	Absorption term to be updated here

Here is the caller graph for this function:

◆ update_velocity_absorption_coriolis()

subroutine multiphase_eos::update_velocity_absorption_coriolis	(	type( state_type ), dimension( : ), intent(in)	states,
		integer, intent(in)	ndim,
		integer, intent(in)	nphase,
		real, dimension( :, :, : ), intent(inout)	velocity_absorption
	)

:Computes velocity absorption associated to coriolis forces from diamond information

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
ndim	Number of dimensions
nphase	Number of phases
velocity_absorption	Absorption term to be updated here

Here is the caller graph for this function:

◆ update_velocity_source()

subroutine multiphase_eos::update_velocity_source	(	type( state_type ), dimension( : ), intent(in)	states,
		type( multi_dimensions ), intent(in)	Mdims,
		type ( multi_field ), intent(inout)	u_source
	)

:Computes velocity source from diamond information

Parameters

state	Linked list containing all the fields defined in diamond and considered by Fluidity
Mdims	Data type storing all the dimensionrs describing the mesh, fields, nodes, etc.

Here is the caller graph for this function:

Variable Documentation

◆ flooding_hmin

real, parameter multiphase_eos::flooding_hmin = 1e-5

Functions/Subroutines

Variables

Detailed Description

Function/Subroutine Documentation

◆ assign_equation_of_state()

◆ calculate_absorption2()

◆ calculate_all_rhos()

◆ calculate_capillary_pressure()

◆ calculate_component_rho()

◆ calculate_diffusivity()

◆ calculate_porous_rho_drhop()

◆ calculate_porousmedia_absorptionterms()

◆ calculate_rho_drhodp()

◆ calculate_solute_dispersity()

◆ calculate_u_source_cv()

◆ calculate_viscosity()

◆ cap_bulk_rho()

◆ density_polynomial()

◆ diffjwl()

◆ flash_gas_dissolution()

◆ get_devcappressure()

◆ get_material_absorption()

◆ get_relperm()

◆ get_rockfluidprop()

◆ initialise_porous_media()

◆ jwl()

◆ jwldensity()

◆ retrieve_reference_density()

◆ saturation_temperature()

◆ update_velocity_absorption()

◆ update_velocity_absorption_coriolis()

◆ update_velocity_source()

Variable Documentation

◆ flooding_hmin
