Solving Combinatorial Problems using Reinforcement Learning

Combinatorial optimization problems are frequently characterized by being intractable for classical algorithms or prone to suboptimal solutions. Such problems naturally arise in logistics (e.g., vehicle routing), scheduling (e.g., job shop), network design (e.g., flow), finance (e.g., portfolio selection), and beyond. Even minor improvements in these domains can yield substantial benefits in cost, efficiency, or strategy. However, designing heuristics and metaheuristics to tackle their complexity is time-consuming.

Reinforcement Learning (RL) has excelled at sequential decision-making tasks in fields ranging from autonomous driving and industrial control to robotics, protein folding, theorem proving, and multiagent games such as chess and go, where it has achieved superhuman performance.

In this exemplar, we will focus on learning to use Reinforcement Learning for solving sequential combinatorial problems, where an optimal strategy involves taking specific actions in a sequence while also responding to a probabilistic setting (environment). Notably, Reinforcement Learning is able to learn the state and action space, so it is able to effectively search these spaces for optimal solutions as opposed to exhaustive searches in classical algorithms, without any heuristics that require expert knowledge to correctly derive.

We will start by implementing a foundational algorithm, Tabular Q Learning, then learn how to apply it in a pre-supplied environment, involving the famous Monty Hall problem, where we will also explore hyperparameter tuning and visualisation of training. After this, we will learn how you can apply RL to any problem space of interest by creating your own environment, where we will walk through an example implementing an environment from scratch for the seminal News Vendor problem from inventory management.

This exemplar was developed at Imperial College London by Omar Adalat in collaboration with Dr. Diego Alonso Alvarez from Research Software Engineering and Dr. Jesús Urtasun Elizari from Research Computing & Data Science at the Early Career Researcher Institute.

Learning Outcomes 🎓

After completing this exemplar, students will:

• Explain the core principles of Reinforcement Learning, and be able to identify when and where it is applicable to a problem space, with a particular focus on combinatorial problems for this project.
• Develop an implementation of a foundational algorithm, Tabular Q Learning, starting from basic principles and concepts.
• Gain the ability to perform experimental validation of the trained Reinforcement Learning algorithm, visualising the learning over training episodes.
• Design hyperparameter tuning configurations that can automatically be applied to retrieve the optimal set of hyperparameters.
• Generalise to non-supplied environments by learning how to create your own Reinforcement Learning environment, allowing you to apply Reinforcement Learning to any problem space that you are interested in.

Target Audience 🎯

This exemplar is broadly applicable to anyone interested in solving sequential decision problems, which comes up ubiquitously across many domains and industries (e.g. protein synthesis, self-driving cars, planning & scheduling, and strategic games). Specifically, although we focus on sequential combinatorial problems which are a specific flavour of sequential decision problems, the underlying concepts are the same between both.

Our exemplar suitable for students, researchers and engineers alike, and academic prerequisite knowledge is not assumed, aside from some confidence in using Python.

Prerequisites ✅

Academic 📚

• Basic familiarity with Python & basic programming skills is required to solve the exercises notebooks
• Some math background in the basics of set theory and probability theory is helpful but not required

System 💻

• Astral's uv Python package and project manager
• An integrated development environment (IDE) for developing and running Python, Visual Studio Code (VS Code) with Python & Jupyter Notebook extensions is the easiest to set up and use. VS Code should automatically prompt you to install the required extensions that you need, but you can refer to here for the Python extension and the Jupyter extension is available for notebook support
• 10 GB of disk space

Getting Started 🚀

1. Start by cloning the repository, either using the GitHub interface or Git directly (git clone https://github.com/ImperialCollegeLondon/ReCoDE-Solving-Combinatorial-Problems-using-Reinforcement-Learning).
2. Install Astral's uv if not already installed from the following URL: https://docs.astral.sh/uv/
3. Run the command uv sync in the cloned repository directory. This will install the correct version of Python (scoped to the directory under uv) and gather all dependencies needed.
4. Create a virtual environment under which the Jupyter Notebooks will run under, which will be scoped to the project directory. Simply run uv venv --python 3.12. When running any notebook, use the virtual environment created for Python 3.12 in the current directory's path, VS Code will give you a list selection of virtual environments to run under (you can also switch this in the top right of a notebook as of the time of writing).
5. Ensure that your notebook's working directory is set to the root of the project directory (the top level folder that lists notebooks, README.md, src, etc). If you are using VS Code, this is already specified by .vscode/settings.json of this repository. If you are using a different IDE, be sure to specify this equivalently, it will be evident that this is working if notebooks are able to properly import all local imports.
6. Navigate to the five notebooks in the directory /notebooks/ and complete them in order, running the exercises which will be checked against automated tests and checking the solutions if at any time you are stuck!

Disciplinary Background 🔬

Reinforcement Learning is a powerful learning paradigm in Artificial Intelligence & Computer Science. While Deep Learning and general Machine Learning are very interesting, often the focus is on making a single isolated decision as in the tasks of classification or regression. Reinforcement Learning, which at the state-of-the-art level also uses Deep Learning for effective learning, is important to learn and master for solving more complex tasks that involve sequential decisions.

Specifically, as it solves sequential decision problems, it is incredibly useful in an interdisciplinary manner for various problems that arise such as the aforementioned: scheduling, protein synthesis, finance, autonomous vehicles and beyond.

Software Tools 🛠️

• Python, with version and dependencies managed by Astral's uv
• Weights & Biases, a web platform for experiment tracking best practices and hyperparameter tuning

A selection of key Python libraries/packages used are listed below: - Gymnasium, allowing to define custom RL environments which conform to a standard interface - Pygame, for visualisation of the environments - Matplotlib, for visualisation of training results by plotting charts and diagrams - Jupyter Notebooks, for literate programming & interactive content

Project Structure 🗂️

Overview of code organisation and structure.

.
├── notebooks
│ ├── 1-Intro-to-RL.ipynb
│ ├── 2-Tabular-Q-Learning.ipynb
│ ├── 3-Experiments.ipynb
│ ├── 4-Custom-Envs-News-Vendor.ipynb
│ ├── 5-Conclusion.ipynb
├── src
│ ├── environments
│ ├───── monty_hall
│       │          └── env.py
│       │          └── state.py
│       │          └── renderer.py
│       │          └── discrete_wrapper.py
│ ├───── news_vendor
│       │          └── env.py
│       │          └── state.py
│       │          └── renderer.py
│       │          └── discrete_wrapper.py
│ ├── rl
│   │   └── common.py
│   │   └── tabular_q_learning.py
├── docs
└── test

Code is organised into logical components:

• notebooks for tutorials and exercises
  • solutions contains full solutions to all exercises, implementing all incomplete functions
  • extras contains notebooks that allow you to interactively visualise the Monty Hall and News Vendor environments
• src for core code
  • monty_hall provides the full implementation of the Monty Hall Gymnasium environment. This is something you are expected to import in for Notebook 3. However, later on you can explore this directory in terms of how everything is implemented, for example the discrete state space wrapper, action masking, and visualisation. It may be useful as a reference for any environments you create in the future!
  • news_vendor is a full reference/target implementation for Notebook 4.
  • rl is a reference implementation for Notebook 2, particularly focused on Tabular Q Learning.
• docs for documentation
• test for testing scripts

Best Practice Notes 📝

• Package (dependency) management and Python version management is provided by uv, which allows a perfectly replicable development environment
• Reference code is entirely documented and commented using Google's Style of Python Docstrings
• Experiments are stored and tracked using Weights & Biases, which allows long-term access to results of experiments, accompanied by all necessary information to replicate such experiments such as hyperparameters

Estimated Time ⏳

Task	Time
Notebook 1. Intro to RL	3 hours
Notebook 2. Tabular Q Learning	6 hours
Notebook 3. Experiments	2 hours
Notebook 4. Custom environment: News Vendor	4 hours
Notebook 5. Conclusion	3 hours

Total time: 18 hours

Additional Resources 🔗

• For building your Reinforcement Learning knowledge:
  • Mastering Reinforcement Learning, which is a book accompanied by videos, providing an excellent overview of the various Reinforcement Learning methods out there
  • Reinforcement Learning: An Introduction, a seminal book with its latest edition published in 2018, by Richard S. Sutton and Andrew G. Barto. This book is considered foundational, and both authors heavily contributed to Reinforcement Learning research and helped start the field. However, this book is more on the theoretical side.
  • Spinning Up in Deep RL by OpenAI, which provides a great overview of the state-of-the-art methods (e.g. PPO and actor-critic methods), particularly with deep reinforcement learning.
    • If you are not familiar with Deep Learning, consider looking at:
      • Dive into Deep Learning, free online book, with code accompanying each section
      • fast.ai courses, covering advanced deep learning methods from the foundations accompanied by practical implementations
• Additional combinatorial environments are available at:
  • Jumanji
  • OR-gym, OR stands for Operations Research
• Specifically for attaining better performance in combinatorial RL, you may want to investigate:
  • More advanced exploration methods, other than greedy-epsilon, starting with Boltzmann
  • Pointer Networks, used by some methods such as AlphaStar
  • Stochastic Q Learning for handling large action spaces
  • Abstraction methods for lowering the complexity of the state and action space

Licence 📄

This project is licensed under the BSD-3-Clause license.
